UNITY Lasers ELITE 20 PRO FB4 (IP65)

The Unity ELITE 2 PRO FB4 IP65 is a 2-Watt full color RGB diode-based laser system, with Pangolin's FB4 media server integrated inside a robust housing. Our ELITE 2 PRO FB4 is ideal for lighting designers as well as special FX companies, who want to integrate lasers, into any multimedia setup.

FB4 External System

CURRENTLY OUT OF STOCK. CONTACT SALES@PANGOLIN.COM FOR INFORMATION ON WHEN MORE UNITS WILL ARRIVE.

FB4 External is designed for users who want the capabilities of our FB4 control hardware, without having to integrate the hardware directly inside of their laser system. FB4 External features our FB4 DMX control hardware inside of a custom housing, giving you complete control from a PC, lighting console (using DMX or ArtNET), or in Auto Mode.

FB4 External includes our award-winning laser control software QuickShow completely free, providing you with over 2,000 pre-programmed laser cues, and all the tools you need to create your own custom laser content.Try a FREE DEMO of QuickShow, by Clicking Here.

Unity Lasers Elite 20 Pro FB4 (IP65)

USD 12,010.00

Cantidad

Product Name:	Unity ELITE 2 PRO
Type Of Laser:	Full-colour, Semiconductor diode laser system
Guaranteed Optical Output:	>2,000mW
Suitable For:	Smaller-sized venues and indoor events; laser shows and laser graphic displays
System Control:	Pangolin FB4 [Ethernet, ArtNet, DMX, ILDA \| PC, Lighting Console, Auto Mode]
Scanning System:	30,000 Points per second @ 8°
Scan Angle:	50°
Safety:	Fully complies with the latest EN 60825-1 and FDA regulations
Weight:	8kg
Package Includes:	Power cord, 5M CAT5 cable, E-STOP box with 10M cable, Set of 4 safety keys, 3-pininterlock bypass plug, User guide.
R \| G \| B [mW]:	390 \| 650 \| 1100
Beam Size [mm]:	2 x 4
Beam Divergence:	<1mrad [Full Angle]
Modulation:	Analog 100kHz
Power Requirements:	100-230V/50Hz
Consumption:	Max. 200W
Operation Temperature:	10-40 °C
Ingress Rating:	IP 20
System Features:	All the adjustments, such as power output of each colour, X & Y axes invert, X & Y size and position, etc., are managed digitally by the FB4 control system. Scanning system protection. Daisy chain of emergency STOP signal for multiple system "one-hit" operation.
Laser Safety Features:	Keyed interlock, Emission delay, Magnetic interlock, Scan-fail safety, Mechanical shutter, Adjustable aperture masking plate.
Notice:	*Due to Advanced Optical Correction technology used in our laser systems, each laser colour's optical power output may slightly differ from the specification of the respective laser module(s) installed. This does not affect the total guaranteed power output.
Dimensions [mm]:	Length: 238 Width: 246 Height: 175

Unity Lasers Elite 20 Pro FB4 (IP65)

Specifications:
